PD173 LED Pendant Light - UPSHINE Lighting North America

Features

The simple and round shape can be coordinated with a variety of use environments.
Create an atmosphere through the lines of the diffuse reflection ripples, emphasizing the sense of decoration and line design.
The color of the lamp body is customized according to the personality.
Quick install: Pendant with surface mounted bracket.
Internal flicker free driver.
Triac dimming available.

Model No.	Watts	CCT	Luminaire CCT ±5%	Efficiency	Lumens (±10%)	Voltage	DIM	UGR	CRI	Beam angle
PD173A-8-8W-D(White Outside & Golden Inside)	8W	3000K	2700K	47lm/W	395lm	AC120V	Triac	-	>80	115
PD173A-8-8W-D(White Outside & Golden Inside)	8W	4000K	3450K	49lm/W	400lm					115
PD173A-8-8W-D(Black Outside & Copper Inside)	8W	3000K	2300K	25lm/W	220lm					130
PD173A-8-8W-D(Black Outside & Copper Inside)	8W	4000K	2900K	30lm/W	250lm					130
PD173A-8-8W-D(Copper Outside & White Inside)	8W	3000K	3050K	84lm/W	650lm					125
PD173A-8-8W-D(Copper Outside & White Inside)	8W	4000K	4050K	86lm/W	700lm					125
PD173A-12-15W-D(White Outside & Golden Inside)	15W	3000K	2700K	54lm/W	815lm					115
PD173A-12-15W-D(White Outside & Golden Inside)	15W	4000K	3450K	58lm/W	860lm					115
PD173A-12-15W-D(Black Outside & Copper Inside)	15W	3000K	2300K	36lm/W	540lm					130
PD173A-12-15W-D(Black Outside & Copper Inside)	15W	4000K	2900K	38lm/W	570lm					130
PD173A-12-15W-D(Copper Outside & White Inside)	15W	3000K	3100K	93lm/W	1400lm					125
PD173A-12-15W-D(Copper Outside & White Inside)	15W	4000K	4100K	103lm/W	1560lm					125

Remarks: All above efficacy and lumens are subject to white finish @4000K, please check IES files for accurate data.
